1. Power Supply: AC380V, 50/60Hz, 1.3kW
2. Overall Dimensions: L1905mm × W660mm × H1750mm
3. Strapping Specifications: Min. packaging size: W300mm × H200mm
4. Working Table Height: 450–700mm (select one)
5. Load Capacity: 100kg
6. Strapping Speed: ≤2.5 seconds/strap
7. Strapping Tension: 0–60kg (adjustable)
8. Strapping Pattern: Parallel 2–4 straps, with modes including photoelectric control, manual, etc.
9. Table roller conveyor: when strapping is not required, direct conveying is possible.
10. Strap Specifications: Width 9–15 (±0.1)mm, Thickness 0.55–1.0 (±0.1)mm (select one).
11. Strap Reel Specifications: Width 160–180mm, Inner diameter 200–210mm, Outer diameter 400–500mm.
12. Bonding Method: Heat fusion, bottom bonding, bonding area ≥90%, bonding position deviation ≤2mm.
13.Machine Weight: 330kg
14. Machine-grade strapping tape must be used.
15. Models available:
15.1 Low-table and high-table;
15.2 With powered conveyor and without powered conveyor;
15.3 Standard type and high-speed type;
15.4 Servo tape head and standard type;
16. The strapping machine has certain requirements for strap material and manufacturing process.
